Product Introduction

Product Overview

The 1.5 Ton Electric Stacker is a professional material handling equipment designed for efficient stacking, loading, unloading and short-distance transportation of goods. It is widely used in warehouses, workshops, logistics centers, supermarkets and other occasions, especially suitable for narrow spaces and indoor operations that require environmental protection and low noise. We provide five models of this series, namely HZCDDH1516, HZCDDH1520, HZCDDH1525, HZCDDH1530 and HZCDDH1535, which differ mainly in lifting height, to meet the diverse stacking needs of different customers.

As a practical and cost-effective electric stacker, this product adopts a stand-on operation mode, which is flexible and labor-saving, allowing operators to complete operations efficiently with simple training. It is driven by electricity, which is environmentally friendly and pollution-free, and the operation noise is low, which will not affect the working environment. At the same time, the overall structure is compact, with a small turning radius, which can easily pass through narrow passages and operate in small spaces, greatly improving the utilization rate of the workplace and work efficiency.

Product Specifications

The following are the detailed specifications of the 1.5 Ton Electric Stacker, covering models, dimensions, performance, motor and battery parameters, which can help you fully understand the product performance:

Features	Unit	HZCDDH1516	HZCDDH1520	HZCDDH1525	HZCDDH1530	HZCDDH1535
Model	-	HZCDDH1516	HZCDDH1520	HZCDDH1525	HZCDDH1530	HZCDDH1535
Drive Mode	-	Electric	Electric	Electric	Electric	Electric
Operation Mode	-	Stand-on	Stand-on	Stand-on	Stand-on	Stand-on
Rated Load Capacity	kg	1500	1500	1500	1500	1500
Load Center Distance	mm	600	600	600	600	600
Lifting Height	mm	1600 (1st Stage Mast)	2000 (2nd Stage Mast)	2500 (2nd Stage Mast)	3000 (2nd Stage Mast)	3500 (2nd Stage Mast)
Fork Size	mm	601701150	601701150	601701150	601701150	601701150
Maximum Fork Outer Spacing (685 mostly)	mm	685/550	685/550	685/550	685/550	685/550
Battery Voltage/Rated Capacity	V/Ah	48V 30AH	48V 30AH	48V 30AH	48V 30AH	48V 30AH
Drive Control Type	-	AC	AC	AC	AC	AC

Product Features

Stable Load Capacity

The rated load capacity of all models is 1500kg, with a load center distance of 600mm, which can stably handle various standard pallets and goods, meeting the daily stacking and handling needs of most small and medium-sized enterprises. The reasonable load design ensures the safety and stability of the operation, and avoids the risk of tipping caused by overload or unbalanced load.

Flexible and Maneuverable

Adopting a stand-on operation mode, the overall body is compact, with an overall width of only 820mm and a turning radius of 1400mm, which can easily pass through narrow aisles (the aisle width for standard pallets is only 2300mm). It is very suitable for operations in small warehouses and workshops with limited space, and can greatly improve the utilization rate of the workplace.

Durable Tire Configuration

All models are equipped with polyurethane wheels, including support wheels (80*65), drive wheels (160*50) and balance wheels (115*55). Polyurethane wheels have the advantages of wear resistance, pressure resistance, low noise and no damage to the ground, which are suitable for indoor ground operations and can extend the service life of the equipment.

Efficient and Energy-Saving

It adopts AC drive control, with stable power output and high energy conversion rate. The drive motor (S2 60MIN) power is 0.8kw, and the lifting motor (S3 15%) power is 2.2kw, which can balance power and energy consumption. The 48V battery configuration ensures stable endurance, and it can work continuously for a long time after being fully charged, meeting the needs of all-day operation.

Safe and Reliable

Equipped with an electromagnetic braking system, the braking effect is stable and sensitive, which can stop quickly in case of emergency, ensuring the safety of operators and goods. The uniform ground clearance design (28mm under the mast, 50mm at the wheelbase center) can avoid jamming caused by uneven ground, and improve the stability of the equipment during operation.

Diverse Lifting Options

Five models are available, with lifting heights ranging from 1600mm to 3500mm, including one-stage and two-stage masts. Customers can choose the appropriate model according to their own stacking height needs, which is widely applicable to different storage heights and scenarios, helping to optimize vertical storage space utilization.

Application Scenarios

The 1.5 Ton Electric Stacker is widely used in various indoor material handling scenarios, especially suitable for occasions that require environmental protection, low noise, small space and efficient stacking. Its main application scenarios include:

Warehouses and logistics centers

Used for stacking, loading and unloading of pallets and goods, short-distance transportation between storage areas, and improving the efficiency of warehousing operations.

Factory workshops

Used for handling raw materials, semi-finished products and finished products between production lines, reducing manual handling and improving production efficiency. It is suitable for hardware, pipe materials and heavy finished goods stacking.

Supermarkets and retail stores

Used for stacking and handling goods in the background warehouse, which is flexible and does not occupy space, and will not affect the normal operation of the store.

Food and pharmaceutical factories

The electric drive mode is pollution-free and low-noise, which meets the environmental protection requirements of food and pharmaceutical production, and is suitable for clean workshop operations

Quality and Maintenance

We attach great importance to the quality of products. The 1.5 Ton Electric Stacker adopts high-quality materials and components, and undergoes strict quality inspection during the production process to ensure that each equipment leaving the factory meets the quality standards. The overall structure of the equipment is simple, the wearing parts are few, and the daily maintenance is convenient, which can effectively reduce the maintenance cost and extend the service life of the equipment.

Daily maintenance precautions: Regularly check the battery power and charge it in time to avoid over-discharge; check the wear of tires and replace them in time if there is damage; check the braking system and hydraulic system to ensure that there is no leakage and the braking is sensitive; clean the equipment regularly to remove dust and debris on the surface and inside of the equipment.

Packaging and Shipping

Packaging: We use export-standard packaging, and each electric stacker is wrapped with film and packed in a suitable export carton to prevent damage during transportation. We can also provide customized packaging according to customer requirements.

Shipping: We can arrange shipping according to customer needs, including sea, air and express. The delivery time is determined according to the order quantity and model, and we will ensure on-time delivery to meet customer needs. The sample delivery time is 5-7 days.

FAQ

Q: What is the difference between the five models of this 1.5 ton electric stacker?

A: The main difference is the lifting height and mast type. HZCDDH1516 adopts a first-stage mast with a lifting height of 1600mm, and the other four models adopt a second-stage mast with lifting heights of 2000mm, 2500mm, 3000mm and 3500mm respectively. Other parameters are basically the same.

Q: What is the battery life of the equipment?

A: The equipment is equipped with a 48V 30AH/32AH battery, which can work continuously for 6-8 hours after being fully charged, which can meet the needs of all-day.
